Outer Rear Diffuser Tunnel

Outer Rear Diffuser Tunnel

Store / Rear Diffusers
£499.00
In stock
Product Details

Your aero setup wouldn't be complete without some underfloor air management, that is where a Rear Diffuser comes in. Essentially a large Venturi Tunnel that allows the low pressure fast moving underbody air to rejoin the high pressure air behind the vehicle in a controlled linear fashion. Utilising the bernouli principle, a rear diffuser will create a high pressure point at the throat of the diffuser, which is where the downforce is generated, and will help to pull the air through from under the vehicle more effeciently.

This Outer Rear Diffuser is typically used either side of our centre diffuser in a 4WD or RWD setup, but can also be used as a pair on smaller vehicles or as part of our modular diffuser system where you can mix and match to suit your installation, manufactured in full carbon fibre with foam core reinforcement, you can create a truly functional rear diffuser to reduce drag and increase downforce to suit almost any vehicle.
Trimable to suit if necessary, the rear diffuser can either be run off the existing underbody if smooth enough, or you can run a sectional flat floor (doesn't have to be full) just in front of the diffuser. All of which needs to be adequately secured to the vehicle using the appropriate hardware.


Specification

Material: Carbon Fibre (2x2 Twill, Bi-Axial and Foam Core)
Resin Infused producing high-strength & low weight parts
Designed using CFD to ensure optimum performance
Dimensions each: 1400mm x 225mm x 250mm (LxWxH)

Sold as a single part


Installation

As with any downforce generating part, the proper installation is key to unlocking the performance gains. Therefor you must ensure your new diffuser is mounted sufficiently to the structural members of the vehicle (Chassis, Sub Frame, Pick Up Points etc), this will allow the downforce loads to be transfered to the vehicle correctly.
Typically you should be aiming for at least 3-4 mounting points, spead evenly across the diffuser surface, using solid mounting bracketry (Steel, Aluminium or Titanium). We can always advise on this further on a case by case basis, as every vehicle is different and each installation may have its own requirements (permanently mounted, slide off & on, adjustable etc).
Just remember, the more solid the diffuser is mounted, the less deflection it will experience and the more downforce will be produced by the vehicle.
